Electrical Lug Sizing Dimension Graphs and Charts.

Below are the various, single wire (one barrel) stocked electrical lugs available through LugsDirect.com. All parts are arrange by manufacturer, wire range, and then variant of part (if applicable). The part number is linked to more product information, and the PDF print is linked to the most current schematic of that part number. Click on the PDF button for more sizing dimensions, and information.



For dual wire (or barrel) lugs click here.




lug-dimensions-chartlug-dimensions-chartlug-dimensions-chartlug-dimensions-chartlug-dimensions-chartlug-dimensions-chart

IHI Connectors-S Series Lugs-Single Wire
Wire Range
Part
Number
&
PDF Print
Fig. No.

Dim A
(US in.)
(METRIC)
Dim B
(US in.)
(METRIC)
Dim C
(US in.)
(METRIC)

Dim D
(US in.)
(METRIC)

Dim L
(US in.)
(METRIC)

Dim T
(US in.)
(METRIC)

Dim d
(US in.)
(METRIC)

Bolt
size

Screw
Option
AWG 6-14
1
1.06
27.0mm
.50
12.7mm
.38
9.5mm
.38
9.5mm
.25
6.4mm
.09
2.3mm
.26
6.6mm
1/4"
6mm
Slotted
AWG 6-14
1
1.06
27.0mm
.50
12.7mm
.38
9.5mm
.38
9.5mm
.20
5.1mm
.09
2.3mm
.20
5.2mm
#10
5mm
Slotted
AWG 6-14
1
1.06
27.0mm
.50
12.7mm
.50
12.7mm
.38
9.5mm
.25
6.4mm
.09
2.3mm
.28
7.1mm
1/4"
6mm
Slotted
AWG 4-14
1
1.06
27.0mm
.50
12.7mm
.50
12.7mm
.38
9.5mm
.25
6.4mm
.09
2.3mm
.27
6.9mm
1/4"
6mm
Slotted
AWG 2-14
1
1.16
29.4mm
.56
14.8mm
.50
12.7mm
.47
11.9mm
.31
7.9mm
.09
2.3mm
.28
7.1mm
1/4"
6mm
Slotted
AWG 2-14
2
1.16
29.4mm
.56
14.8mm
.50
12.7mm
.47
11.9mm
.31
7.9mm
.09
2.3mm
.28
7.1mm
1/4"
6mm
5/32"
(or) 4mm
Hex Socket
AWG 2-14
2
1.16
29.4mm
.56
14.8mm
.50
12.7mm
.47
11.9mm
.27
6.9mm
.09
2.3mm
.17
18.2mm
#8
4mm
5/32"
Hex Socket
AWG 2-14
4
1.16
29.4mm
.56
14.3mm
.50
12.7mm
.47
11.9mm
.33
8.5mm
.09
2.3mm
.26
6.6mm
1/4"
6mm
Slotted
AWG 1/0-14
1
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.41
10.3mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
Slotted
AWG 1/0-14
2
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.41
10.3mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
3/16"
Hex Socket
AWG 1/0-14
2
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.41
10.3mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
5mm
Hex Socket
AWG 1/0-14
4
1.46
37.2mm
.77
19.0mm
.640
16.3mm
.66
16.7mm
.38
9.5mm
.19
4.8mm
.33
8.3mm
5/16"
8mm
3/16"
Hex Socket
AWG 2/0-14
1
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.44
11.1mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
Slotted
AWG 2/0-14
2
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.44
11.1mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
3/16"
Hex Socket
AWG 2/0-14
2
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.44
11.1mm
.19
4.8mm
.28
7.1mm
1/4"
6mm
5mm
Hex Socket
AWG 2/0-14
5
.01
0.4mm
.75
19.1mm
.61
15.5mm
.62
15.8mm
.50
12.7mm
.25
6.4mm
.19
4.8mm
SEE
PDF
3/16"
Hex Socket
AWG 2/0-14
3
1.69
42.9mm
.91
23.0mm
.63
15.9mm
.63
15.9mm
1.03
26.2mm
.19
4.8mm
.28
7.1mm
#10
5mm
3/16"
Hex Socket
AWG 2/0-14
4
1.47
37.3mm
.81
20.6mm
.63
15.9mm
.63
15.9mm
.41
10.3mm
.19
4.8mm
.27
6.7mm
1/4"
6mm
3/16"
Hex Socket
250kcmil-6
2
2.00
50.8mm
1.06
27.0mm
.91
23.0mm
1.00
25.4mm
.44
11.1mm
.22
5.5mm
.34
8.7mm
5/16"
8mm
3/8"
Hex Socket
250kcmil-6
2
2.00
50.8mm
1.06
27.0mm
.79
20.0mm
1.00
25.4mm
.53
13.5mm
.22
5.5mm
.40
10.3mm
3/8"
10mm
5/16" AF
(or) 8mm AF
Hex Socket
350kcmil-6
2
2.00
50.8mm
1.13
28.6mm
1.00
25.4mm
1.00
25.4mm
.50
12.7mm
.25
6.4mm
.34
8.7mm
5/16"
8mm
3/8"
Hex Socket
350kcmil-6
2
2.00
50.8mm
1.13
28.6mm
1.00
25.4mm
1.00
25.4mm
.50
12.7mm
.25
6.4mm
.41
10.4mm
3/8"
10mm
3/8"
Hex Socket
350kcmil-6
2
2.00
50.8mm
1.13
28.6mm
1.00
25.4mm
1.00
25.4mm
.50
12.7mm
.25
6.4mm
.53
13.5mm
1/2"
12mm
3/8"
Hex Socket
500kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.41
10.3mm
3/8"
10mm
1/2"
Hex Socket
500kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.41
10.3mm
3/8"
10mm
10mm
Hex Socket
500kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
1.07
27.2mm
.31
7.9mm
.41
10.3mm
3/8"
10mm
1/2"
Hex Socket
500kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.53
13.5mm
1/2"
12mm
1/2"
Hex Socket
600kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.41
10.3mm
3/8"
10mm
1/2"
Hex Socket
600kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.41
10.3mm
3/8"
10mm
10mm
Hex Socket
600kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.53
13.5mm
1/2"
12mm
1/2"
Hex Socket
600kcmil-4
2
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.53
13.5mm
1/2"
12mm
10mm
Hex Socket
600kcmil-4
6
2.75
69.9mm
1.50
38.1mm
1.38
34.9mm
1.25
31.8mm
.63
15.9mm
.31
7.9mm
.53
13.5mm
1/2"
12mm
1/2"
Hex Socket
750kcmil-1/0
2
2.84
(72.1)
1.81
(46.0)
1.36
(34.5)
1.50
(38.1)
.63
(15.9)
.50
(12.7)
.53
(13.5)
1/2"
12mm
1/2"
Hex Socket
